Chapter 4 Electric Components
4.2.2 PS-096C
No. Signal Name Direction Opposite Side
1 Not Connected
PS-100 USB
2 Not Connected
3 Not Connected
4 VBUS -
5 D- <->
6 D+ <->
7 GND -
8 Not Connected
XJ2
No. Signal Name Direction Opposite Side
1 VH -
PS-097
2 VH -
3 12V -
4 5V -
5 GND -
6 GND -
