4-12
Capter 4 Electric Components
No. Signal Name Direction Opposite Side
1 VH ->
Cash Drawer
2 GND -
XJ5
No. Signal Name Direction Opposite Side
1 SPAN_SW <-
PS-063, PS-055
2 GND -
XJ6
No. Signal Name Direction Opposite Side
1 Not Connected
PS-067
2 XIN_2.5MHz ->
3 RESET ->
4 SCLK ->
5 Not Connected
6 +5V -
7 Not Connectted
8 DRDY <-
9 GND -
10 VIN -
11 Not Connected
XJ7
No. Signal Name Direction Opposite Side
1 1A ->
Step motor
2 1B ->
3 2A ->
4 2B ->
XJ8
No. Signal Name Direction Opposite Side
1 VCC -
Thermal Head
2 GND -
3 CLK ->
4 LATCH ->
5 Not Connected
6 STB1 ->
7 Not Connected
XJ9
