jcb 19C-1E User Manual

Maintenance
Miscellaneous
Miscellaneous
Fire Extinguisher
Check (Condition)
In addition to the operator check the extinguisher must be serviced every 12 months by a suitably qualified
person.
1. Examine the fire extinguisher for damage and leaks.
2. Make sure the fire extinguisher is correctly attached.
3. Make sure that the gauge indicates that the extinguisher is charged i.e. the needle is in the green segment
3.1. If the needle is in or very near the red segment at either end of the gauge, the extinguisher must be
serviced or replaced.
4. Make sure the safety pin is correctly installed.
Figure 114.
B
A
A Gauge B Safety Pin
148 9831/8250-4 148
JCB © Admin Pimteam - 23/06/2021 05:32.

jcb 19C-1E Specifications

General

Battery Type	Manganese laminated Lithium-ion
Battery Rated Capacity	14.8 kWh (3 Pack) 19.8 kWh (4 Pack)
Charging	On-board charger with direct connection from AC mains power supply
Charging Time	110V – 12 hrs 230V – 8 hrs
Fast Charging (Optional)	Off-board charger, with connection to 415V 3-Phase supply Charging time <2 hrs
System Voltage	48V
Motor Type	AC permanent magnet
Motor Power	7 kW continuous 20kW peak
Operating Modes	L – 1200rpm G – 1600rpm H – 1800rpm Auto Kick Up – 2300rpm, 2 speed tracking only
Thermal Limitations	Operation: -10oC to +46oC Charging: -10oC to +40oC
