Operation
Instruments
Instruments
General
Indicators for the batteries and related systems are mounted in the instrument cluster in the right hand console.
Instrument Panel
WARNING If there is a fault with the machine electrical system an error may be displayed on the instrument
panel. Contact your JCB dealer. Do not try to repair it yourself.
The gauges, warning and indicator lamps are grouped together on the instrument panel. When a warning lamp
comes on, an alarm will sound.
Figure 27.
A Battery level indicator gauge B Warning and indicator lamps
Battery level: The needle position shows the battery charge level.
47 9831/8250-4 47
