jcb 19C-1E User Manual

Operation
Working with the Dozer Blade
Backfilling
When you backfill on a slope, pile the material on the high side of the trench when possible.
Move the dozer blade level to the ground. Work at right angles to the trench, fill a dozer blades width at a time.
Leave any spillage until the trench is filled.
Use the spillage to finish the job by driving the length of the trench with the dozer blade low to the ground.
Figure 53.
67 9831/8250-4 67
JCB © Admin Pimteam - 23/06/2021 05:32.

jcb 19C-1E Specifications

General

Battery Type	Manganese laminated Lithium-ion
Battery Rated Capacity	14.8 kWh (3 Pack) 19.8 kWh (4 Pack)
Charging	On-board charger with direct connection from AC mains power supply
Charging Time	110V – 12 hrs 230V – 8 hrs
Fast Charging (Optional)	Off-board charger, with connection to 415V 3-Phase supply Charging time <2 hrs
System Voltage	48V
Motor Type	AC permanent magnet
Motor Power	7 kW continuous 20kW peak
Operating Modes	L – 1200rpm G – 1600rpm H – 1800rpm Auto Kick Up – 2300rpm, 2 speed tracking only
Thermal Limitations	Operation: -10oC to +46oC Charging: -10oC to +40oC
