Maintenance
Access Apertures
Figure 99.
A Retaining strap
9. Open the rear counterweight door.
Close
To close the rear counterweight door, follow the reverse sequence of open procedure.
Hydraulic Compartment Cover
Open
1. Make the machine safe with the excavator arm lowered.
Refer to: Maintenance Position (Excavator End Lowered) (Page 116).
2. Use the ignition key to unlock the cover.
3. Open the cover. Refer to Figure 100.
123 9831/8250-4 123
