Technical Data
Fluids, Lubricants and Capacities
Fluids, Lubricants and Capacities
General
JCB recommend that you use the JCB lubricants shown as they have been verified by JCB for use on JCB
machines. However, you could use other lubricants that are equivalent to the JCB standards and quality or
offer the same machine component protection.
Table 19. Fluids, Lubricants and Capacities
CapacityItem
L
Fluid/Lubricant JCB Part
Number
Container
Size
(1)
Track Gearbox
(each)
0.3 JCB Oil HP SAE 30 (Not Multigrade) 4001/0305 20L
Track Idler Wheels 0.3 JCB HP90 Gear Oil 4000/0305 20L
Track Rollers (bot-
tom)
0.025 JCB HP90 Gear Oil 4000/0305 20L
Hydraulic System 28
Hydraulic Tank 15
-20°C (-4.0°F) to 46°C (114.7°F):JCB
Hydraulic Fluid HP 32
4002/1025 20L
Slew Ring Bearings As required JCB HP Grease 4003/2017 0.4kg
Slew Ring Gear
Teeth
As required JCB Special Slew Pinion Grease 4003/1619 0.4kg
All Other Grease As required JCB Special HP Grease (Blue) 4003/1501 0.4kg
(1) For information about the different container sizes that are available (and their part numbers), contact your
local JCB dealer.
156 9831/8250-4 156
JCB © Admin Pimteam - 23/06/2021 05:32.

jcb 19C-1E Specifications

General

Battery Type	Manganese laminated Lithium-ion
Battery Rated Capacity	14.8 kWh (3 Pack) 19.8 kWh (4 Pack)
Charging	On-board charger with direct connection from AC mains power supply
Charging Time	110V – 12 hrs 230V – 8 hrs
Fast Charging (Optional)	Off-board charger, with connection to 415V 3-Phase supply Charging time <2 hrs
System Voltage	48V
Motor Type	AC permanent magnet
Motor Power	7 kW continuous 20kW peak
Operating Modes	L – 1200rpm G – 1600rpm H – 1800rpm Auto Kick Up – 2300rpm, 2 speed tracking only
Thermal Limitations	Operation: -10oC to +46oC Charging: -10oC to +40oC
