JOHNSON CONTROLS
178
FORM 201.23-NM2
ISSUE DATE: 3/9/2015
SECTION 6 - TECHNICAL DATA
FIGURE 27 - CHILLER CONTROL BOARD, RELAY BOARDS, AND MICROGATEWAY, 2 COMPRESSOR
COMPONENT LOCATIONS (CONT'D)
LD10580
CHILLER
CONTROL
BOARD
MICROGATEWAY
(OPTIONAL)
RELAY BOARD #1
RELAY BOARD #2
RS-232/485 JUMPER
CLOCK JUMPER (CLK)
JP2
JP4, JP5, & JP6
mA
• • •
V
â–¼
â–² â–²
â–¼
JUMPER POSITION
