Johnson Controls York YCIV A Series - FIGURE 28 - Chiller Control Board, Relay Boards, and Microgateway, 3 Compressor

JOHNSON CONTROLS
179
SECTION 6 - TECHNICAL DATA
FORM 201.23-NM2
ISSUE DATE: 3/9/2015
6
FIGURE 28 - CHILLER CONTROL BOARD, RELAY BOARDS, AND MICROGATEWAY, 3 COMPRESSOR
COMPONENT LOCATIONS (CONT'D)
50069
CHILLER
CONTROL
BOARD
RELAY BOARD #1
RELAY BOARD #2
RELAY BOARD #3
MICROGATEWAY
(OPTIONAL)
JP4, JP5, & JP6
mA
• • •
V
▼
▲ ▲
▼
JUMPER POSITION
