JOHNSON CONTROLS
276
FORM 201.23-NM2
ISSUE DATE: 3/9/2015
SECTION 8 - MICROPANEL
The month can be selected by keying in the numerical
value to select the day. After the month is selected, the
(ENTER) key must be pressed to store the data.
A “0” must be keyed in for months 01
through 09. The panel will automatically
provide the abbreviation of the month.
Pressing the ▼ (DOWNARROW) key again scrolls
to the year:
CLOCK FRI 18-JUN-2005 10:15:33 AM
YEAR = XXXX
The year can be selected by keying in the numerical
value to select the year. After the year is selected, the
(ENTER) key must be pressed to store the data.
Pressing the ▼ (DOWNARROW) key again scrolls
to the hour:
CLOCK FRI 18-JUN-2005 10:15:33 AM
HOUR = XX
The hour can be selected by keying in the numerical
value for the hour. After the hour is selected, the
(ENTER) key must be pressed to store the data.
One or two “0’s” must be keyed in for
hours 00-09.
Pressing the ▼ (DOWNARROW) key again scrolls
to the minute:
CLOCK FRI 18-JUN-2004 10:15:33 AM
MINUTE = XX
The minute can be selected by keying in the numerical
value for the hour. After the minute is selected, the
(ENTER) key must be pressed to store the data.
One or two “0’s” must be keyed in for
minutes 00 through 09.
Pressing the ▼ (DOWNARROW) key again scrolls
to AM/PM:
CLOCK FRI 18-JUN-2004 10:15:33 AM
AM/PM ◄ ► = XX
AM/PM can be selected by pressing the ◄ or ►
(ARROW) keys. After the meridian is selected, the
(ENTER) key must be pressed to store the data.
Pressingthe▼(DOWNARROW)keyagainscrollsto
the time format selection:
CLOCK FRI 18-JUN-2004 10:15:33 AM
TIME FORMAT ◄ ► = XXXXXXX
The time format may be displayed in either a 12 hour
or 24 hour format. Selection can be changed by press-
ingthe◄or►(ARROW) keys. The (ENTER) key
must be pressed to store the data.
Schedule Key Operation
The Daily Schedule must be programmed for the unit
start and stop times. To set the schedule, press the
SCHEDULE key. The display will provide a message
allowing access to 2 types of schedule information:
SCHEDULE CHOOSE SCHEDULE TYPE
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXX
The schedule types are:
• UNIT OPERATING SCHEDULE
• (Default selection)
• SOUND LIMIT SCHEDULE
(Only if Sound Limiting is enabled by the factory
when the option is installed.)
The schedule type (UNIT OPERATING SCHEDULE
or SOUND LIMIT SCHEDULE) may be changed by
pressing the ◄ (LEFT ARROW) or ► (RIGHT AR-
ROW) keys followed by the (ENTER) key. The se-
lection must be entered by pressing the (ENTER)
key before a schedule display will appear.
