Johnson Controls York YCIV A Series User Manual

JOHNSON CONTROLS
185
SECTION 6 - TECHNICAL DATA
FORM 201.23-NM2
ISSUE DATE: 3/9/2015
6
FIGURE 34 - FAN CONTACTORS AND 3T TRANSFORMER, 2 COMPRESSOR
COMPONENT LOCATIONS (CONT'D)
LD10584
FAN CONTACTORS
4CR-9CR
3T TRANSFORMER
(24VAC to SCR Gate Driver Board and VSD Logic Board)
