JOHNSON CONTROLS
198
FORM 201.23-NM2
ISSUE DATE: 3/9/2015
SECTION 6 - TECHNICAL DATA
COMPRESSOR COMPONENTS
LD10596
FIGURE 46 - COMPRESSOR COMPONENTS
SUCTION
STRAINER
STATOR
KEY
ROTOR
MOTOR/ROTOR
HOUSING
MALE
ROTOR
FEMALE
ROTOR
BEARINGS
• SHIMS
SHIMS
BEARINGS
DISCHARGE
HOUSING
OIL
FILTER
MOTOR
TERMINALS
STATOR
