Johnson Controls York YCIV A Series - FIGURE 29 - VSD Logic Board

JOHNSON CONTROLS
180
FORM 201.23-NM2
ISSUE DATE: 3/9/2015
SECTION 6 - TECHNICAL DATA
FIGURE 29 - VSD LOGIC BOARD
LD10582
COMPONENT LOCATIONS (CONT'D)
VSD
LOGIC BOARD
SCR TRIGGER BOARD
