SECTION 9 - MAINTENANCE
FORM 201.23-NM2
ISSUE DATE: 3/9/2015
9
CHILLED LIQUID TEMPERATURES
Entering Temp. = ºF(ºC)
Leaving Temp. = ºF(ºC)
OUTDOOR AMBIENT TEMPERATURES
OAT = ºF(ºC)
VSD FREQUENCY
Actual =
Command =
UNIT OPERATING TEMPERATURES AND PRESSURES
VSD BUS VOLTAGE
Bus 1 =
Bus 2 =
VSD INTERNAL AMBIENT TEMPERATURE
Ambient Temp. = ºF(ºC)
VSD COOLING SYSTEM STATUS
ON OFF
VSD IGBT BASEPLATE TEMPS
T1 = ºF(ºC)
T2 = ºF(ºC)
SYSTEM OPERATING TEMPERATURES, PRESSURES AND CURRENTS
SYSTEM PRESSURES
SYS 1 SYS 2 SYS 3 SYS 4
Oil PSIG (kPa)
Suction PSIG (kPa)
Discharge PSIG (kPa)
SYSTEM TEMPERATURES
SYS 1 SYS 2 SYS 3 SYS 4
Oil ºF(ºC)
Suction ºF(ºC)
Discharge ºF(ºC)
SAT Suction ºF(ºC)
SAT Superht ºF(ºC)
SAT Discharge ºF(ºC)
Dsch Superht ºF(ºC)
MOTOR TEMPERATURES
SYS 1 SYS 2 SYS 3 SYS 4
T1 ºF(ºC)
T2 ºF(ºC)
T3 ºF(ºC)
COMPRESSOR SPEED
SYS 1 SYS 2 SYS 3 SYS 4
Speed %
SYSTEM CURRENT
SYS 1 SYS 2 SYS 3 SYS 4
Current AMPS
SYS 1 SYS 2 SYS 3 SYS 4
Current %FLA
