7-6
7.1.5 TD Angle and Ship Speed Correction
Transducer Angle Correction
・Function・ It is possible to set within the range of [-20.0 - ±00.0 - +20.0] degree. Standard: ±00.0
The numerical value changes into the direction of the minus with key in 0.1 degrees
step, and changes into the direction of the plus with key in 0.1 degrees step.
It is necessary to install the direction of the prow mark of the ship prow with the transducer
according to accuracy.
Moreover, the installation angle of the transducer shifts when the direction of ship speed is
biased to the left or the right though the straight advancement sailing is done and it is
displayed. Correct the direction on the screen.
The correction of the installation angle can be corrected within the range of maximum
±20 degrees.
About Transducer Angle Correction
1) Input the value of (-) when the direction of ship speed is biased right though it sails
straight.
When the transducer turns to the prow on the port side by 3 degrees, input -3.0
degrees of the correction value.
2) Input the value of (+) when the direction of ship speed has been biased left.
When the transducer turns to the prow on the starboard side by 3 degrees. input +3.0
degrees of the correction value.
Operation Standard Menu: “Installation setting” menu/TD Angle correction: ±00.0 degrees
Ship Speed Correction
・Function・ It is possible to set within the range of [-20.0 - ±00.0 - +20.0] %. Standard: ±00.0
The numerical value changes into the direction of the minus with key in 0.1 % step, and
changes into the direction of the plus with key in 0.1 % step.
About Ship Speed Correction
Correct the speed based on the result of the speed examination. Please input the value of
(+) when you correct the speed in the direction of the plus, and input the value of (-) when
correcting it in the direction of the minus.
Operation Standard Menu: “Installation setting” menu/ Ship speed correction: ±00.0 %
Draft Correction
・Function・ It is possible to set within the range of [ ±00.0 - +20.0] m. Standard: ±00.0
The numerical value changes into the direction of the minus with key in 0.1 m step, and
changes into the direction of the plus with key in 0.1 m step.
About Draft Correction
The set correction value is reflected in the depth of screen display and the draft
value outputting NMEA.
Operation Standard Menu: “Installation setting” menu/ Draft correction: ±00.0 m
Delay Correction
・Function・ It is possible to set within the range of [ ±00.0 - +40.0] sec. Standard: ±00.0
The numerical value changes into the direction of the minus with key in 0.1s. step, and
changes into the direction of the plus with key in 0.1 s step.
About Delay Correction
The set correction value corrects the delay due to the difference in processing
between the heading value and COG value that NMEA has entered.
Operation Standard Menu: “Installation setting” menu/ Delay correction: ±00.0 s
▼
▲
▲
▼
▲
▼
▲
▼
To Next Page
