4-58
4.12 Initial Settings of GNSS/Beacon/SBAS
Set the GNSS sensor.
JLR-4350 supports multi-GNSS.
The available GNSS system combinations are as follows.
(1) GPS mode
a) GPS
(2) Multi-GNSS mode
a) GPS+QZSS
b) GPS+GLONASS
c) GPS+QZSS
d) GPS+QZSS+GLONASS
e) GPS+QZSS+BeiDou
Even in multi-GNSS mode also, GLONASS and BeiDou cannot be used concurrently.
DGLONASS and DBeiDou are not supported. When using DGPS by SBAS/beacon, use it in GPS
mode.
In multi-GNSS mode also, position fixing is performed without using the systems that cannot be
received by the satellites.
4.12.1 Setting a positioning system
Select a GNSS system to be used.
In the processor with two sensors installed, the sensors must be set individually.
In this example, sensor 1 is connected. The same procedure is applied for setting sensor 2.
Procedure
1. Enter a password by referencing "4.2.11. Entering a password with CODE INPUT”.
Password: 1650
2.
  
GPS MODE Description
GPS Operates in GPS mode. Only GPS is used.
To perform DGPS b
y
SBAS/beacon, set “GPS”.
GPS+QZSS Operates in multi-GNSS mode.
GPS and QZSS are used concurrentl
y
.
GPS+GLONASS Operates in multi-GNSS mode.
GPS and GLONASS are used concurrentl
y
.
GPS+BDS Operates in multi-GNSS mode. GPS and BeiDou are used concurrentl
y
.
GPS+QZSS+GLONASS Operates in multi-GNSS mode.
GPS, QZSS, and GLONASS are used concurrentl
y
.
GPS+QZSS+BDS Operates in multi-GNSS mode.
GPS, QZSS, and BeiDou are used concurrentl
y
.
GPS: Global Positioning System. Positioning system that is operated by the U.S.A.
QZSS: Quasi-Zenith Satellite System (Michibiki). Positioning system that is operated by
Japan.
GLONASS: Global Navigation Satellite System. Positioning system that is operated by Russia.
DeiDou: Positioning system that is operated by China.
In JLR-4350, only QZSS No.1 can be used. Correction data cannot be received from QZSS.
Memo
