8-2
8.2.2 Environment
・ Operating Temperature -25℃～+55℃
・Storage Temperature -40℃～+70℃
・Vibration IEC60945 ed.4 conformant
・EMC IEC60945 ed.4 conformant
・Waterproofing IP56
8.3 NDC-4100 Processor Unit
8.3.1 Basic
・Memories Waypoints 10000points maximum
Event/Mark 1000points maximum (include MOB)
Track 2000points maximum
Route 100routes maximum
・Route plan 512 waypoints per one route
・Magnetic Variation Automatic or manual
・Navigation Calculation Grate circle or Rhumb line selectable
・Alert Arrival, Anchor, Boundary, XTD, No position fix, Speed, Trip, HDOP
Temperature
*
, Depth
*
・Plot Function Scale 0.2,0.5,1,2,5,10,20,50,100,200,300NM
Interval 1～60min (1 sec) or 0.01～99.99NM (0.01NM) selectable
・Data Input/Output IEC61162-1 Output ×5, Input ×2
IEC61162-2 Output ×1, Input ×1
Buffer Unit: IEC61162-1 Output ×8
LAN×2
・Dry Contact Output ×4, Input ×1
・Remote maintenance Available
・Unit Distance, Speed：NM,kn or km,km/h or mi,mi/h
Height, Depth：m or ft or fm
Temperature：℃ or ℉
・Loran C/A Latitude and Longitude can be converted into the Loran time difference
・Language Japanese or English
・8ch Buffer Built-in
・2ch Select Switch Built-in
・Power Supply Voltage DC12/24V（+30%,-10%）
・Power Consumption 15W 以下
JLR-8600：less than 25W
・Dimensions 264(W)mm×100(H)mm×281(D)mm
・Mass Approximately 2.2kg
・Software version R60.0
*：External sensor must be connected
8.3.2 Environment
・Operating Temperature -15℃～+55℃
・Storage Temperature -25℃～+70℃
・Vibration IEC60945 ed.4 conformant
・EMC IEC60945 ed.4 conformant
・Waterproofing IP22
