JRC JR-8600 User Manual

8-3
8.3.3 Interface
1) Serial Transmission
Channel Si
g
nal Input / Output Forma
t
Data IN/OUT 1 RS-422 Input IEC61162-2/NME
A
Outpu
t
IEC61162-2/NMEA/JRC/SWITCH/SC-104
Data IN/OUT 2 RS-422 Input IEC61162-1/NME
A
Output IEC61162-1/NMEA/JRC/SWITCH/SC-104
Data IN/OUT 3 RS-422 Input IEC61162-1/NME
A
Outpu
t
IEC61162-1/NMEA/JRC/SWITCH/SC-104
DATA OUT 4 RS-422 Outpu
t
IEC61162-1/NMEA/JRC/SWITCH/SC-104
DATA OUT 5 RS-422 Outpu
t
IEC61162-1/NMEA/JRC/SWITCH/SC-104
DATA OUT 6 RS-422 Outpu
t
IEC61162-1/NMEA/JRC/SWITCH/SC-104
Buffer Unit RS-422 Outpu
t
IEC61162-1/NME
A
DATA IN/OUT 7 RS-232C Input IEC61162-1/NME
A
Output IEC61162-1/NMEA/Printer data for DPU-414
1-1) NMEA
・Specification NMEA0183
・Version Ver1.5,2.1,2.3,4.0
・Bit Rate 4800,9600,19200,38400bps
・Data Bit 8bit
・Parity None
・Start Bit 1bit
・Stop Bit 1bit
・Output Sentence GGA,RMC,GLL,VTG,GSA,GSV,DTM,GBS,GRS,GST,ZDA,GNS,
ALR,APB,BOD,BWC,BWR,RMB,XTE,ZTG,AAM,RTE,WPL,ACK
HDT
*
,THS
*
,DBT
*
,DPT
*
,MTW
*
,CUR
*
,VBW
*
,VHW
*
・Output Interval 1s,2s,3s,4s,5s,6s,7s,8s,9s,OFF
・Input Sentence HDT,THS,DBT,DPT,MTW,CUR,VBW,VHW,ACK,WPL,RTE,ALR
*External sensor must be connected
Note) Some combinations of output sentence, bit rates, and output intervals may not be possible.
1-2) IEC
・Specification IEC61162-1 Ed.5
1-3)JRC
・Specification ：JRC
・Bit Rate ：1200bps
・Data Bit ：8bit
・Parity ：None
・Start Bit ：1bit
・Stop Bit ：2bit
2) Dry Contact
Channel Input / Output None
Contact 1,2,3,4 Outpu
t
A
lert, 200p/NM, 400p/NM,
A
CK
Contact 5 Input
A
CK
3)LAN
・Specification ：IEC61162-450/JRC
・Bit Rate ：10/100Mbps
・Shared route ：JRC Format
・Data output ：NMEA,IEC

JRC JR-8600 Specifications

General

Brand	JRC
Model	JR-8600
Category	GPS
Language	English
