4-64
4.12.10 Setting a beacon
Set DGPS by using a beacon.
For a processor with two sensors connected, the sensors must be set individually.
In this example, sensor 1 is connected. The same procedure is applied for setting sensor 2 also.
Procedure
1. Enter a password by referencing "4.2.11. Entering a password with CODE INPUT”.
Password: 1650
2.
3. Set a beacon station selection method.
The selection method is outlined below.
(1) AUTO: Selects an optimum beacon station from the GPS position.
(2) MANUAL: Set a frequency and a baud rate of the beacon station manually.
(3) SEMI AUTO: Automatically selects an optimum beacon station from up to three stations that
are selected from the adjacent stations at random. JLR-8600 does not support
this function.
(4) MONITOR: JLR-8600 does not support this function.
(1) AUTO
a) Tap .
(2) MANUAL
a) Tap .
b) Tap to confirm the setting.
MANUAL Description
FREQUENCY Set a frequency.
BITRATE Set a bit rate.
To Next Page
