1-1
Chapter 1 Equipment Overview
1.1 Functions
This equipment (JLR-8600) is a GPS navigator with a JLR-4350GPS sensor that is connected to
the NWZ-1650 display unit and the NDC-4100 processing unit.
JLR-4350, which is a multi-GNSS receiver that is capable of receiving data from GPS as well as
GLONASS or BeiDou, operates around-the-clock to measure positions with high accuracy anywhere in
the world and in all weather conditions by using the GPS satellite and the GLONASS satellite, or the
BeiDou satellite, and produces highly reliable positioning results. In addition, the GPS navigator can
increase the accuracy of position fixing by receiving correction data from the DGPS beacon station and
SBAS satellites.
1.2 Features
Registration of up to 100 routes and 10000 waypoints
Many output ports installed with the built-in buffer unit
Enables sharing of a route with ECDIS by the mounted LAN
High visibility 6.5-inchi large colour LCD
Provided with many graphic display modes
Mutual acknowledgment through a contact or ALR
Improved operability by touch panel and abundant menus
High reliability by the multi-GNSS receivers (GPS/GLONASS/BeiDou/QZSS/SBAS)
Built-in RAIM function
