2-3
2.2 JLR-4350 GPS Sensor
2.3 NDC-4100 Processor
6 pins Connector
Approx. φ19mm
Base
Data Cable 15m
Approx. φ6mm
Mounting Screw
1 inch 14 UNS-2B
Mounting Screw hole
Cover
Cable Inlet
Earth terminal
Radome
