4-8
4.2 Basic Operation
4.2.1 Turning on the power of the unit
When the power of the equipment is turned on by pressing the Power key, the startup screen
appears.
When installation is completed, self-diagnosis starts and the setting value confirmation screen is
changed to the normal screen.
4.2.2 Startup
1) Normal startup
If all the self-diagnosis results are ‘OK’ and all the settings of the processor and sensor
settings match, the screen is switched to the normal screen automatically.
If the power for the equipment is not turned on, check the main power supply of the power
board, power cable connection to the processor, or cable connection to the display unit.
Attention
Startup screen
Self diagnosis
Setting value
confirmation
To Next Page
