1-2
1.3 Configuration
1.3.1 Standard Configuration
JLR-8600
No Name Model Q'ty Note
1 GPS Sensor Unit JLR-4350 1
1-1 Screw Adapter MTV302007A 1
1-2 Mounting Band MPBP02520 1 Include 2 bands
1-3 Instruction manual 7ZPNA4695 1 English
1-4 Cable guard rubber MPPK31462 1
2 Processor Unit NDC-4100 1
2-1 Fuse
MF51NR 250V 5
MF51NR 250V 2
1
MF51NR 250V 5 ：4 Fuses
MF51NR 250V 2 ：1 Fuses
3 Display Unit NWZ-1650 1
3-1
Model
Identification
Plate
MPNN50903 1
3-2 Clamp Filter 5MBIR00009 1
3-3 Flush mount kit MPBX50891 1
4 Display cable CFQ-7540 1 LAN 15m for DISPLAY
5 Instruction manual 7ZPNA4699 1 7ZPNA4698(Japanese)/7ZPNA4699(English)
NWZ-1650
No Name Model Q'ty Note
1 Display Unit NWZ-1650 1 Refer to JLR-8600(3～3-3)
2 Instruction manual 7ZPNA4699 1 7ZPNA4698(Japanese)/7ZPNA4699(English)
To Next Page
