3-6
3.1.5 Analogue screen
The analogue screen displays the course, waypoint bearing, and CDI in graphic format. During
route execution, the screen displays the off-course and distance to the waypoint.
The ship speed meter can be displayed by using or .
Main screen
Sub screen (Speed)
▼Bearing from the
own ship's position
to the waypoint
Course indicator bar
Route deviation indicator bar
Deviation from the route
Course
Distance from the
own ship's position
to the waypoint
Speed
Center of the route
