4-18
4.4 Registering Waypoints
To execute a route, a waypoint must be registered in a waypoint list.
This equipment allows registration of 10000 waypoints.
A waypoint list is divided into three areas and it is managed by numbers from 1 to 11024.
1 to 10000: Waypoints that are registered in this equipment are registered.
10001 to 10512: Waypoints of the shared active routes that are sent from ECDIS are registered.
10513 to 11024: Waypoints that were used by a temporary route are registered.
While waypoints from number 1 to number 10512 are saved and are not cleared even if the
power is turned off, waypoints from number 10513 to number 11024 are cleared if the power is
turned off.
Waypoints can be set up to North latitude/South Latitude 89 degrees.
4.4.1 Displaying a waypoint list
Registered waypoints (waypoint numbers from 1 to 10000) can be displayed.
Waypoint number 00001 is registered as “HOME PORT”.
Procedure
1.
A waypoint list is displayed.
The position that is registered in HOME in a waypoint list can be set easily as a
waypoint by the GOTO function.
It is useful to register a point that is set as a waypoint frequently (such as home port).
The GOTO function can be set from on each screen.
Memo
Symbol
Waypoint number
Position
Comment
To Next Page
