4.19 Displaying external equipment information
Information on the ship speed through water, water temperature, water depth, and tidal stream can
be displayed by entering it on the external equipment.
It is possible to make the setting of each layer of the tidal stream to be displayed. Up to five layers
can be displayed.
Procedure
1. Display navigation aid information screen 4 by selecting and tapping several
times.
2.

3. By using or , select a layer (layer A to layer E) to be set.
Item Description
SELECT SELECT: Set a Layer Number.
A
LL: Displa
y
s the data havin
g
the hi
g
hest La
y
er Number.
LAYER Specif
y
a La
y
er Number to be displa
y
ed.
DATA SETTING METHOD SELECT: Set a data set number.
A
LL: Displa
y
s data of all the data set numbers.
DAT
A
Specif
y
a data set number to be displa
y
ed.
Recommended setting
Item LAYER
A
LAYER B LAYER C LAYER D LAYER E
SELECT SELECT SELECT SELECT SELECT SELECT
LAYER 1 2 3 4 5
DATA SETTING METHOD ALL ALL ALL ALL ALL
DATA
－ － － － －
