4-65
4.12.11 Setting SBAS
Set DGPS by SBAS.
For a processor with two sensors connected, the sensors must be set individually.
In this example, sensor 1 is connected. The same procedure is applied for setting sensor 2 also.
Procedure
1. Enter a password by referencing "4.2.11. Entering a password with CODE INPUT”.
Password: 1650
2.
4.12.12 Displaying a beacon station list
JLR-8600 does not support this function.
Display a list of all the beacon stations.
Up to 1024 stations can be displayed.
For a processor with two sensors connected, the sensors must be set individually.
In this example, sensor 1 is connected. The same procedure is applied for setting sensor 2 also.
SBAS Description
SAT SEARCH AUTO: Selects an optimum SBAS satellite.
MANUAL: Set a SBAS satellite number.
SBAS When SAT SEARCH is set to MANUAL, set a SBAS satellite number.
TYPE 0 Set the use of TYPE 0 data (test data) to ON/OFF.
Normall
, set to “OFF”.
RANGING Set whether the SBAS satellite is used for positioning in the same way as the
GPS satellite.
Since JLR-4350 is not equipped with the ran
in
function, set to “OFF”.
To Next Page
