JRC JR-8600 - Page 119

5-3
Sub GPS Sensor
Alert Numbe
r
Alert text Causes Category Priority
113 GPS4 no fix No Fix B W
116 GPS5 no fix No Fix B W
119 GPS6 no fix No Fix B W
012 GPSm HDOP ove
r
HDOP value has been exceeded
setting level B C
013 GPSm no heading No Heading B W
060 GPSm Ant open GPS Antenna Open B W
061 GPSm Ant short GPS Antenna Short B W
062 GPSm ROM error GPS core ROM Error B W
063 GPSm RAM erro
r
GPS core RAM Erro
r
B W
064 GPSm RTC erro
r
GPS core RTC Erro
r
B W
065 Cntlm ROM error ROM Error (Controller of Sensor) B W
066 Cntlm RAM erro
r
RAM Error (Controller of Sensor) B W
067 Cntlm FPGA erro
r
FPGA Error (Controller of Sensor) B W
068 Cntlm BACK error
Data Backup Error (Controller of
Sensor) B W
069 GPSm ID erro
r
Sensor Product information Erro
r
B C
070 GPSm core1 er
r
GPS core 1 Erro
r
B W
071 GPSm core2 err GPS core 2 Error B W
072 GPSm core3 er
r
GPS core 3 Erro
r
B W
073 GPSm x gyro er
r
X
axis Gyroscope Erro
r
B W
074 GPSm y gyro err Y axis Gyroscope Error B W
075 GPSm z gyro er
r
Y axis Gyroscope Erro
r
B W
076 GPSm g sen er
r
Tilt mete
r
Erro
r
B W
077 GPSm temp err Temperature Sensor Error B W
078 GPSm inner er
r
Sensor inside Erro
r
B W
079 GPSm core1no prg GPS core 1 program Erro
r
B W
080 GPSm core2no prg GPS core 2 program Error B W
081 GPSm core3no prg GPS core 3 program Erro
r
B W
082 GPSm Vibration Excessive Vibration B W
083 GPSm ctrl no prg Controller program Error B W
103 GPS1 no fix No Fix B W
106 GPS2 no fix No Fix B W
109 GPS3 no fix No Fix B W
113 GPS4 no fix No Fix B W
116 GPS5 no fix No Fix B W
119 GPS6 no fix No Fix B W
Display Unit
Alert Number Alert text Causes Category Priority
150 DISP eMMC err
eMMC Deletion, Write Error
B W
151 DISP E2PROM er
r
EEPROM Deletion, Write Error
B W
152 DISP RAM er
r
RAM Read, Write Error
B W
153 DISP SIO er
r
Serial Port Error
B W
154 DISP LAN err
LAN Port Error
B W
