1-9
NQA-4351A Output Buffer
DC Input Data Output
(IEC61162-1 or NMEA) (IEC61162-1 or NMEA)
Select si
g
nal
Data Output Data Output
(IEC61162-1 or NMEA) (IEC61162-1 or NMEA)
JUMPER SETTING for DC Input
DC Input JUMPER Terminal
DC 12V TB1-IN
1
2 JUMPER ON 9-16V
JUMPER Cable 0.25~2.5mm
3
DC 24V TB1-IN
1
2 JUMPER ON 9-16V
Not connect
Unit： mm
Mass： 0.8 kg
