Recovering the truck in the load direction with and without load
Requirements
– Attachment in home position, see page 192.
– Load handler fully lowered, see page 171 or see page 211.
– Drive wheel brake released, see page 225.
Tools and Material Required
– Tow rope, towing capacity > 5 to..
Procedure
• Switch off the truck, to do this:
• Turn the key in the key switch (8) to the left as far as the stop and remove the
key.
•
Press the red button of the ISM access module (o) twice in a row.
• Press the emergency disconnect switch (9).
• Disconnect the battery.
NOTICE
Risk of damage from the tow rope
During recovery, route the tow rope to the front in such a way as to avoid damaging
hydraulic hoses, electric cables and the attachment.
• Route the tow rope (190) around the lift mast (15) (see illustration).
233
04.19 en-GB
