8.6.3 Approaching the warehouse location with Rack Height Select
Requirements
– Prepare the truck for operation, see
page 138 or see page 139.
– Drive the truck into the narrow aisle and
establish automatic guidance, see
page 159.
Procedure
• Using the numerical keypad (112) enter
the area (206), see page 266.
• Using the numerical keypad (112) enter
the rack number (207), see page 267.
Z
Depending on the current lift height, an
arrow is shown on the driver's display
next to the rack number that has been
entered. This arrow indicates whether
the Main Lift needs to be raised or
lowered to reach the warehouse
location.
268
04.19 en-GB
