Juniper QFX Series - QFX5110 Rack Requirements; Table 23: Physical Specifications for the QFX5110; Table 24: Rack Requirements for the QFX5110

Table 23: Physical Specifications for the QFX5110
WeightDepthWidthHeightProduct SKU
23 lbs (10.43 kg) with 2
power supplies
20.48 in. (52.02 cm) excluding fan
and power supply handles
17.36 in. (44.1 cm)1.72 in. (4.3 cm)QFX5110-48S
24.6 lbs (11.16 kg) with 2
power supplies
20.48 in. (52.02 cm) excluding fan
and power supply handles
17.36 in. (44.1 cm)1.72 in. (4.3 cm)QFX5110-32Q
See Also Standalone Installation Overview on page 85•
• Installing and Removing QFX5110 Hardware Components
QFX5110 Rack Requirements
QFX5110 switches are designed to be installed on four-post racks.
Rack requirements consist of:
•
Rack type
•
Mounting bracket hole spacing
•
Rack size and strength
Table 24 on page 61 provides the rack requirements and specifications for the QFX5110.
Table 24: Rack Requirements for the QFX5110
GuidelinesRack Requirement
Use a four-post rack that provides bracket holes or hole patterns spaced at 1 U
(1.75 in. or 4.45 cm) increments and that meets the size and strength requirements
to support the weight.
A U is the standard rack unit defined in Cabinets, Racks, Panels, and Associated
Equipment (document number EIA-310–D) published by the Electronics Industry
Association.
Rack type
The holes in the mounting brackets are spaced at 1 U (1.75 in. or 4.45 cm), so that
the switch can be mounted in any rack that provides holes spaced at that distance.
Mounting bracket hole spacing
61Copyright © 2019, Juniper Networks, Inc.
Chapter 2: Site Planning, Preparation, and Specifications
