NOTE: If your laptop or PC does not have a DB-9 male connector pin and you
want to connect your laptop or PC directly to a QFX Series device, use a
combination of the RJ-45 cable and RJ-45 to DB-9 adapter supplied with the
device and a USB to DB-9 male adapter. You must provide the USB to DB-9
male adapter.
Table 32: Console Port Connector Pinouts for the QFX Series
DescriptionSignalPin
Request to sendRTS Output1
Data terminal readyDTR Output2
Transmit dataTxD Output3
Signal groundSignal Ground4
Signal groundSignal Ground5
Receive dataRxD Input6
Data carrier detectDCD Input7
Clear to sendCTS Input8
RJ-45 Port, QSFP+ Port, QSFP28 Port, SFP+ Port, and SFP Port Connector Pinout Information
The Tables in this topic describe the connector pinout information for the RJ-45, QSFP+,
QSFP28, SFP+, and SFP ports.
•
Table 33 on page 78—10/100/1000BASE-T Ethernet network port connector pinout
information for EX4300 switches, except EX4300-48MP and EX4300-48MP-S
switches
•
Table 34 on page 78—10/100/1000BASE-T Ethernet network port and
100/1000/2500/5000/10000BASE-T Ethernet network port connector pinout
information for EX4300-48MP and EX4300-48MP-S switches
•
Table 35 on page 79—SFP network port connector pinout information
•
Table 36 on page 80—SFP+ network port connector pinout information
•
Table 37 on page 81—QSFP+ and QSFP28 network module ports connector pinout
information
77Copyright © 2019, Juniper Networks, Inc.
Chapter 2: Site Planning, Preparation, and Specifications
