Unpacking and Mounting the QFX5110
•
Unpacking a QFX5110 on page 88
•
Registering Products—Mandatory for Validating SLAs on page 89
•
Mounting a QFX5110 in a Rack on page 89
Unpacking a QFX5110
The QFX5110 is a rigid sheet-metal structure that houses the hardware components. A
QFX5110 is shipped in a cardboard carton, secured with foam packing material. The carton
also contains an accessory box and a Documentation Roadmap card.
CAUTION: The QFX5110 is maximally protected inside the shipping carton.
Do not unpack the switch until you are ready to begin installation.
To unpack a QFX5110:
1. Move the shipping carton to a staging area as close to the installation site as possible,
but where you have enough room to remove the system components.
2. Position the carton so that the arrows are pointing up.
3. Open the top flaps on the shipping carton.
4. Remove the accessory box and verify the contents against the inventory included in
the box. Table 38 on page 88 lists the inventory of components supplied with a
QFX5110.
5. Pull out the packing material holding the switch in place.
6. Verify the chassis components received:
•
Two power supplies
•
Five fan modules
The QFX5110-32Q-CHAS is shipped without power supplies or fan modules.
7. Save the shipping carton and packing materials in case you need to move or ship the
switch later.
Table 38: Inventory of Components Supplied with a QFX5110
QuantityComponent
1Chassis with five fan modules and two power supplies
Copyright © 2019, Juniper Networks, Inc.88
QFX5110 Switch Hardware Guide
