Table 37: QSFP+ and QSFP28 Network Port Connector Pinout Information (continued)
SignalPin
SDA12
GND13
RX3p14
RX3n15
GND16
RX1p17
RX1n18
GND19
GND20
RX2n21
RX2p22
GND23
RX4n24
RX4p25
GND26
ModPrsL27
IntL28
VccTx29
Vcc130
Reserved31
GND32
TX3p33
TX3n34
GND35
Copyright © 2019, Juniper Networks, Inc.82
