3-32 Keysight B1505A User’s Guide, Edition 12
Accessories
• Input HCSMU (16493S-020) or From HCSMU (16493A-021)
Triaxial connector (Sense) and BNC connector (Force). For connecting 16493S
HCSMU cable from the HCSMU.
• Master Force/Sense
Must be connected to Force/Sense of HCSMU used as the master.
• Slave Force/Sense
Must be connected to Force/Sense of HCSMU used as the slave.
• Input GNDU (16493S-020)
GNDU triaxial connector. For connecting 16493L GNDU cable from the
GNDU.
NOTE Do not put any conductor on the HCSMU Low Force and Low Sense terminals,
outer conductor of the coaxial connectors. Putting conductor of circuit common,
chassis ground, or any potential on causes the measurement error.
