Accessories
2. Serial number label
You need this serial number when using Keysight Technologies telephone
assistance program.
3. Option number label
4. Interlock connector
Interlock connector. For connecting 16493J interlock cable from B1505A.
WARNING Potentially hazardous voltage may be present at the High, Force, Sense, and
Guard terminals when the interlock terminals are shorted on test fixture,
prober station, and such.
Une tension potentiellement dangereuse peut être présente à la borne High
lorsque les bornes de verrouillage sont court-circuitées sur l'équipement de
test, la station de sonde et autres.
5. Earth terminal
Screw terminal for earthing.
6. Digital I/O connector
Input connector is for connecting 16493G cable from the Digital I/O connector
of B1505A.
Output connector is for connecting 16493G cable to the Digital I/O connector of
N1266A, N1268A expander or any accessory.
7. Selector Input connectors
• HVSMU connector
HV(jack) connector. For connecting 16493T HVSMU cable from the
HVSMU or the HVMCU High.
• SMU connectors
Force and Sense triaxial connectors. For connecting 16494A triaxial cable
from the HP/MPSMU.
8. UHC Input connectors
Triaxial connectors. For connecting 16494A triaxial cables from Force and
Sense connectors of the MCSMU. HCSMU is substitutable. Then use 16493S
HCSMU cable, N1254A-103 adapter for Force, and N1254A-517 adapter for
Sense.
