4-2 Keysight B1505A User’s Guide, Edition 12
Installation
This chapter describes how to install Keysight B1505A and accessories.
• “Requirements”
• “Inspection and Installation”
• “Maintenance”
• “About Plug-in Modules”
To change the GPIB address of the B1505A, see “To Change GPIB Address” on
page 4-12.
To control external GPIB devices from the B1505A/EasyEXPERT, see “To Enable
System Controller” on page 4-13.
For the connection of accessories, see Keysight B1505A Configuration and
Connection Guide.
WARNING To avoid electrical shock and instrument damage, turn the all instruments off
before connecting or disconnecting measurement cable.
Pour éviter une décharge électrique et un risque d'endommagement de
l'appareil, mettez tous les appareils hors tension avant de brancher ou de
débrancher le câble de mesure.
WARNING The B1505A, the N1265A ultra high current expander/fixture, and the N1268A
ultra high voltage expander are heavy and require a two person lift.
Le B1505A, le N1265A ultra high current expander/fixture et le N1268A ultra
high voltage expander sont lourds et nécessitent deux personnes pour les
soulever.
CAUTION Do not grab the fixture cover when lifting the N1259A or N1265A test fixture.
WARNING There are potentially hazardous voltages (± 10 kVdc for UHVU, ± 3000 Vdc for
HVSMU, ± 2200 V pulse for HVMCU, ± 200 Vdc for HPSMU, and ± 100 Vdc
for MPSMU) present at the High, Force, Guard, and Sense terminals of the
instruments. To prevent electrical shock, the following safety precautions must
be observed during the use of instruments.
• Use three-conductor AC power cable to connect the instrument to an
electrical ground (safety ground).
For both the N1265A and the N1268A, also connect a wire from an
electrical ground (safety ground) to the earthing terminal.
