Keysight B1505A User’s Guide, Edition 12 4-17
Installation
About Plug-in Modules
Table 4-2 Module Installation Rule
Slot Number and Location Module Type
10
:
:
:
:
:
:
:
1
top
:
:
:
:
:
:
:
:
bottom
B1513A/B/C High Voltage SMU (HVSMU)
B1512A High Current SMU (HCSMU)
B1514A Medium Current SMU (MCSMU)
B1520A Multi Frequency CMU (MFCMU)
B1511A/B Medium Power SMU (MPSMU)
B1510A High Power SMU (HPSMU)
0 GNDU/ADC (always installed)
