Measurement Examples
I-V and Capacitance Measurements Using N1272A
• For I-V measurements:
Category Application Test Description
PowerMOSFET IDSS Drain- Source leak current measurement
IGSS Gate-Source leak current measurement
IGBT ICES Collector-Emitter leak current measurement
IGES Gate-Emitter leak current measurement
PowerDiode IR Inverse current/leak current measurement
N1272A IV Path (N1272A) Making IV measurement path in the N1272A
