Keysight Technologies B1505A

Keysight B1505A User’s Guide, Edition 12 2-33
Introduction
Measurement Resources
Table 2-7 HCSMU Voltage Ranges and Resolutions (HCSMU / DHCSMU)
Table 2-8 HCSMU Current Ranges and Resolutions
NOTE 40 A range and 2 A range
The 40 A range and the 2 A range are available when two HCSMU modules are
installed in the B1505A and connected to the 16493S-020 Dual HCSMU Kelvin
combination adapter or the 16493S-021 Dual HCSMU combination adapter. Two
HCSMU modules can be the DHCSMU which supports ± 40 A (pulse), ± 2 A (DC).
Then the 20 A range is not supported.
When the compliance value is set to > 1 A or < -1 A, the current measurement
range is fixed to the compliance range.
Range
Output Value and
Measurement Value
Setting/Measurement
Resolution
Maximum
Current
Maximum Pulse
Base Value
0.2 V 0  |V|  0.2 V 200 nV ± 20 A / ± 40 A ± 0.2 V
2 V 0  |V|  2 V 2 V ± 20 A / ± 40 A ± 2 V
20 V 0  |V|  20 V 20 V ± 20 A / ± 40 A ± 20 V
40 V 0  |V|  40 V 40 V±1 A / ±2 A± 40 V
Range
Output Value and
Measurement Value
Setting/Measurement
Resolution
Maximum
Voltage
Maximum Pulse
Base Value
10 A0  |I|  11.5 A 10 pA ± 40 V ± 10 A
100 A0  |I|  115 A 100 pA ± 40 V ± 100 A
1 mA 0  |I|  1.15 mA 1 nA ± 40 V ± 1 mA
10 mA 0  |I|  11.5 mA 10 nA ± 40 V ± 10 mA
100 mA 0  |I|  115 mA 100 nA ± 40 V ± 100 mA
1 A
0  |I|  1.15 A
a
a. Maximum value is 1 A for DC output or measurement by HCSMU.
1 A ± 40 V ± 1 A
2 A
0  |I|  2.02 A
b
b. Maximum value is 2 A for DC output or measurement.
2 A ± 40 V ± 2 A
20 A 0  |I|  20 A 20 A ± 20 V ± 100 mA
40 A 0  |I|  40 A 40 A ± 20 V ± 200 mA
