Figure 5 on page -18 shows an example of modules arrangement in the
M9514A AXIe 14-slot chassis.
Figure 5 Example of M8030A module arrangement
# 10-11 M8051A module
# 12-13 M8051A module
# 14 M8192A multi-channel synchronization module, mandatory
Slot Number Module
