394 Keysight M8070A Programming Guide
5 SCPI Command Reference
:PLUGin:EDIagram Subnode
The M8070A system software provides quick design analysis with the eye
diagram capability. The measurement allows a quick check for the DUT’s
signal output and determines the signal quality. The eye contour lines
display the measured eye at a deeper BER level, for accurate results. The
eye diagram generates a three dimensional graph of the bit error rate
(BER). This measurement helps in determining and analyzing the quality of
the DUT’s signal output. The eye diagram results comprise of voltage(y),
time(x) and BER(z). The measurement comes with the set of Acquisition
and Evaluation Parameters which are used to configure the measurement
run. The Acquisition parameters can only be configured before the
measurement starts (i.e. during the measurement run you cannot change
the value of Acquisition parameter); however the Evaluation parameters
can be configured any time even after the measurement has been run.
This subnode has the following SCPI structure:
:EDIagram
:BREak
:CATalog?
:CONTinue
:DELete
:NEW
:RESet
:STARt
:STEP
:STOP
:ACQuisition
:EVALuation
:FETCh[:RESult]
:SHOW
:RUN
...
...
...
...
...
