Recommended Programming Techniques 2
Symbol Coding Descriptions
Bit Coding
To encode a bit coded (binary) symbol 1, 2, or 3 bits are needed. This
depends on the use of mask and squelch.
Table 8 Plain bit coding without using mask or squelch
Table 9 Mask is used
Table 10 Squelch is used
Table 11 Mask and squelch are used
Bit Offset/Range Bit (range) Name Description
0 Data Data bit
Bit Offset/Range Bit (range) Name Description
0 Data Data bit
1 Mask Mask (ignored on DataOut)
Bit Offset/Range Bit (range) Name Description
0 Data Data bit
1 Squelch Squelch (ignored on DataIn)
Bit Offset/Range Bit (range) Name Description
0 Data Data bit
1 Mask Mask (ignored on DataOut)
2 Squelch Squelch (ignored on DataIn)
