5 SCPI Command Reference
:PLUGin:JTOLerance Subnode
The jitter tolerance commands are used to determine the capacity of a
serial data receiver to tolerate jitter. There are two modes: compliance or
characterization. Jitter frequency is set at multiple test points. At each
point, the jitter amplitude is modulated using various search algorithms to
determine the level of jitter which causes the device to fail. The M8040A
system supports also jitter tolerance measurement using NRZ or PAM-4.
This subnode has the following SCPI structure:
:PLUGin
:JTOLerance
:INSTruments
:GENerator[?]
:ANALyzer[?]
:BSETup
:TBERatio[?]
:CLEVel[?]
:FRTime[?]
:ARTime[?]
:MSETup:
:TEMPlate
:FILE[?]
:FREQuency
:STARt[?]
:STOp[?]
:MTPoints[?]
:NPOints[?]
:MODE[?]
:CMARgin[?]
:ALGorithm[?]
:BINary
:SSIZe[?]
:LINear
:SSIZe[?]
:LOG
:SSIZe[?]
:CLAuto[?]
:GRAPh?
:TLIMits[?]
:TPOints[?]
:CLIMits[?]
:FETCh
:DATA?
