436 Keysight M8070A Programming Guide
5 SCPI Command Reference
:PLUGin:CCAPture Subnode
The M8020A/M8030A Analyzer captures the data received from the device
under test. The captured data bits are displayed in the pattern capture pan
in binary or 8b/10b symbol coding. The received data is compared with the
expected data and the errored bits/symbols are highlighted. The captured
data can be saved for post processing. The maximum capture memory is
2 Gb. However, it also depends on the holdoff length which represents the
amount of symbols in which the trigger events will be ignored.
This subnode has the following SCPI structure:
:CCAPture
:CATalog?
:DELete
:NEW
:RESet
:STARt
:STOP
:SAVE
:TRIGger
:IMMediate
[:ONCE]
:SHOW
:BIT
:PATTern
:VIEW
:SYMBol
:PATTern
:VIEW
:FETCh
...
:ACQuisition
…
:RUN
…
