[SOURce:]ARB:CURRent:TRAPezoid:TOP[:LEVel] <value>, (@<chanlist>)
[SOURce:]ARB:CURRent:TRAPezoid:TOP[:LEVel]? [MIN|MAX,] (@<chanlist>)
[SOURce:]ARB:VOLTage:TRAPezoid:TOP[:LEVel] <value>, (@<chanlist>)
[SOURce:]ARB:VOLTage:TRAPezoid:TOP[:LEVel]? [MIN|MAX,] (@<chanlist>)
Specifies the top current or voltage level of the trapezoid. Referenced to I1 and V1 in the Trapezoid
diagrams.
[SOURce:]ARB:SEQuence:STEP:CURRent:TRAPezoid:TOP[:LEVel] <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:CURRent:TRAPezoid:TOP[:LEVel]? [MIN|MAX,] <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:TRAPezoid:TOP[:LEVel] <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:TRAPezoid:TOP[:LEVel]? [MIN|MAX,] <step#>, (@<chanlist>)
Specifies the top current or voltage level of the trapezoid for Arb sequence steps.
Parameter Typical Return
Current: 0 - maximum|MIN|MAX, *RST MIN
Voltage: 0 - maximum|MIN|MAX, *RST MIN
The maximum value varies, depending on the currentor voltage
rating of the power module.
<top value>
Step 0 - 99, *RST 0 (none)
Programs the top level current: ARB:CURR:TRAP:TOP 2,(@1)
Programs the top level voltage: ARB:VOLT:TRAP:TOP 20,(@1)
Programs a top level for step 0: ARB:SEQ:STEP:CURR:TRAP:TOP 2, 0,(@1)
[SOURce:]ARB:CURRent:TRAPezoid:TOP:TIMe <value>, (@<chanlist>)
[SOURce:]ARB:CURRent:TRAPezoid:TOP:TIMe? [MIN|MAX,] (@<chanlist>)
[SOURce:]ARB:VOLTage:TRAPezoid:TOP:TIMe<value>, (@<chanlist>)
[SOURce:]ARB:VOLTage:TRAPezoid:TOP:TIMe? [MIN|MAX,] (@<chanlist>)
Specifies the time of the top level of the trapezoid in seconds. Referenced to t2 in the Trapezoid
diagrams.
[SOURce:]ARB:SEQuence:STEP:CURRent:TRAPezoid:TOP:TIMe <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:CURRent:TRAPezoid:TOP:TIMe? [MIN|MAX,] <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:TRAPezoid:TOP:TIMe <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:TRAPezoid:TOP:TIMe? [MIN|MAX,] <step#>, (@<chanlist>)
Specifies the time of the top level of the trapezoid in seconds for Arb sequence steps.
Parameter Typical Return
0 – 262.144 | MIN | MAX, *RST 0 <top time>
Step 0 - 99, *RST 0 (none)
Programs a top time for the current trapezoid: ARB:CURR:TRAP:TOP:TIM 2,(@1)
Programs a top time for the voltagetrapezoid: ARB:VOLT:TRAP:TOP:TIM 2,(@1)
Programs a top time for step 0: ARB:SEQ:STEP:CURR:TRAP:TOP:TIM 2, 0,(@1)
