DC Power Module Items Description Part Number
Large Sense Jumpers Two largejumpers for local sensing at the outputconnector.
Only used in N6731B, N6741B, N6754A, N6756A, N6764A,
N6766A, N6773A.
Keysight0360-2935
Phoenix Contact3118151
Sense Connector A 4-pin connector for connecting sense leads. Wires (p/n
5185-8847) are used for local sensing. Only used in N6753A,
N6755A, N6763A, N6765A.
Keysight1253-5830
Phoenix ContactMC 1,5/4-ST-3,5
Module Cal. Certificate A certificate of calibration referenced to the serial number. N/A
Inspect the Unit
When you receive your power analyzer, inspect it for any obvious damage that may have occurred
during shipment. If there is damage, notify the shipping carrier and nearest Keysight Sales and
Support Office immediately. Refer to www.keysight.com/find/assist.
Until you have turned on and checked out the power analyzer, save the shipping carton and packing
materials in case the unit has to be returned.
Review Safety Information
This Keysight N6705C DC Power Analyzer is a Safety Class 1 instrument, which means it has a
protective earth terminal. That terminal must be connected to earth ground through a power source
equipped with a ground receptacle.
Refer to the Safety Summary page at the beginning of this guide for general safety information. Before
installation or operation, review this guide for safety warnings and instructions. Safety warnings for
specific procedures are located at appropriate places throughout this Guide
Some power modules generate voltages exceeding 60 VDC. Ensure that instrument
connections, load wiring, and load connections are either insulated or covered so that
no accidental contact with lethal output voltages can occur.
Observe Environmental Conditions
Do not operate the instrument in the presence of flammable gases or fumes.
The environmental conditions of the power analyzer are documented under Environmental
Characteristics. Basically, the unit should only be operated indoors in a controlled environment.
The dimensions of your instrument as well as an outline diagram are also documented under
Specifications. A fan cools the power analyzer by drawing air through the sides and exhausting it out
the side and back. The instrument must be installed in a location that allows sufficient space at the
sides and back of the unit for adequate air circulation.
Keysight N6705C Operating and Service Guide 49
2 Installation
