LAN Interface as-shipped settings
These settings areoptimized for connecting your power analyzer to a sitenetwork. They should also work well for other network
configurations.
The LAN as-shipped settings can berestored by selecting the System\IO\LAN\Defaults menu.
Get IP Address Automatic
Subnetmask 255.255.0.0
Default gateway 0.0.0.0
Hostname Keysight-<serial number>
mDNS servicename Keysight N67xxx DC Power Analyzer <serial number>
LANservice - VXI-11 Enabled
LANservice - Telnet Enabled
LANservice - mDNS Enabled
LANservice - Web server Enabled
LANservice - sockets Enabled
Web password Blank
Initial N678xA SMU Emulation Mode Settings
The following tables document the emulation mode settings that are applied when the emulation
mode is selected. Emulation mode settings are not saved. N/A means not applicable.
4 Quadrant Power Supply
1
2 Quadrant Power Supply 1 Quadrant Power Supply
Priority mode voltage current voltage current voltage current
Quadrants 4 4 2 2 1 1
Voltage range 6.12 V N/A 6.12 V N/A 6.12 V N/A
Voltage 0 V N/A 0 V N/A 0 V N/A
I limit range 3.06 A N/A 3.06 A
3
N/A 3.06 A
3
N/A
+ I limit 3.06 A N/A 3.06 A
3
N/A min. N/A
– I limit – 3.06 A N/A – 3.06 A
3
N/A – 0.612 A N/A
Current range N/A 3.06 A N/A 3.06 A
3
N/A 3.06 A
3
Current N/A 0 A N/A 0 A N/A 0 A
V limit range N/A 6.12 V N/A 6.12 V N/A 6.12 V
7 SCPI Programming Reference
358 Keysight N6705C Operating and Service Guide
