4 Quadrant Power Supply
1
2 Quadrant Power Supply 1 Quadrant Power Supply
+ V limit N/A 6.12 V N/A 6.12 V N/A 6.12 V
– V limit
1
N/A – 6.12 V N/A min. N/A min.
Outputresistance
2
0 Ω/off N/A 0 Ω/off N/A 0 Ω/off N/A
Outputstate off off off off off off
I limit tracking on on on off off off
V limit tracking
1
on on off off off off
Note 1: N6784A only
Note 2: N6781A and N6785a only
Note 3: 8.16 Afor Models N6785Aand N6786A
Battery Emulator
2
Battery Charger
2
CC Load
CV Load
Voltmeter
Ammeter
Priority mode voltage voltage current voltage current voltage
Quadrants 2 1 1 1 4 4
Voltage range 6.12 V 6.12 V N/A 6.12 V N/A lowest
Voltage 0 V 0 V N/A 5 mV 0 V 0 V
I limit range 3.06 A
3
3.06 A
3
N/A 3.06 A
3
3.06 A
3
3.06 A
3
+ I limit 3.06 A
3
min. N/A min. N/A 3.06 A
3
– I limit – 3.06 A
3
min. N/A max. N/A – 3.06 A
3
Current range N/A N/A 3.06 A
3
N/A lowest N/A
Current N/A N/A – 0.5 A N/A 0 A N/A
V limit range N/A N/A 6.12 V N/A 20.4 V N/A
+ V limit N/A N/A 6.12 V N/A 20.4 V N/A
– V limit
1
N/A N/A min. N/A – 20.4 V N/A
Outputresistance
2
0 Ω/off 0 Ω/off N/A 0 Ω/off N/A 0 Ω/off
Outputstate off off off off on on
I limit tracking off off off off off off
V limit tracking
1
off off off off off off
Note 1: N6784A only
Note 2: N6781A and N6785a only
Note 3: 8.16 Afor Models N6785Aand N6786A
